Thermal Printers

Which printer is right for your job?

Several factors should be considered before buying your own barcode labeling printing system. The primary factor is quantity of material printed – how many labels will you need to print in a given day? Other factors include the type of label material used (rolls, fan-folded packs, or sheets), PC accessibility and printer footprint size.

Equipment is rated based on typical quantities (units = lineal inches of printed material):

Light duty desktop usage (up to 1,000 inches per day)
Light duty industrial usage (up to 25,000 inches per day)
Medium duty industrial usage (up to 100,000 inches per day)
Heavy duty industrial usage (up to 250,000 inches per day)

The typical printing system requires a dedicated PC computer (Windows 95 or higher), which you supply.

Once you have your PC, Thermal Images offers several Printer Packages with everything else you need to get started -- including the printer, power cord/power supply, software, connecting cables and a “starter set” of premium wax ribbons and premium paper labels. All printer packages include free technical support for 90 days via phone, fax or email.

Zebra TLP2844 Printer Package – Desktop - $985

This system is a basic entry level desktop printing system with full functionality software to create custom labels for low volume applications.

Printer	Zebra TLP2844
Duty	Light Duty Desktop
Printing resolution	200 dpi
Maximum Print Speed	4 inches/sec
Maximum Width	4.33 inches
Maximum Ribbon Length	300 LF
Maximum Label Roll OD	5 inches
Warranty	1 year
Print Head Warranty	1 year / 1 million inches

Software: LabelView Basic
Accessories included: printer power supply/cable; PC/printer connecting cable, 12 premium wax ribbons (black, 4.3”x300LF), 1 case of premium paper labels (you choose the size)

Falcon 4D Printer Package – Desktop / Small Industrial - $942

Our most durable desktop printer. Standard software is user-friendly and includes text, barcodes and graphics; database functionality is available as an added option. Holds 984 LF ribbons and 5 inch OD rolls for fewer roll changes. Special design features make ribbons and labels easy to load.

Printer	Falcon 4D
Duty	Light Duty Industrial (Desktop size)
Printing resolution	203 dpi
Maximum Print Speed	6 inches/sec
Maximum Width	4.33 inches
Maximum Ribbon Length	984 LF
Maximum Label Roll OD	5 inches
Warranty	1 year
Print Head Warranty	1 year / 1 million inches

Software: Included (text, barcode, graphics)
Accessories included: printer power cord; PC/printer connecting cable, 12 premium wax ribbons (black, 4.33”x984LF), 1 case of premium paper labels (you choose the size).

Stand alone PS/2 keyboard additional accesory: $100

Datamax I-4208 Printer Package - $2,175

Our Datamax package features our best equipment warranty – 3 years. Datamax printers are simple and easy to use. Includes full featured software. Printer is compatible with larger roll sizes for ribbons and labels for fewer roll changes.

Printer	Datamax I-4208
Duty	Medium Duty Industrial
Printing resolution	200 dpi
Maximum Print Speed	8 inches/sec
Maximum Width	4.33 inches
Maximum Ribbon Length	1181 LF
Maximum Label Roll OD	8 inches
Warranty	3 year
Print Head Warranty	1 year / 1 million inches

Software:, LabelView, BarTender or Label Matrix – your choice (text, barcode, graphics, database)
Accessories included: printer power cord; PC/printer connecting cable, 3 premium wax ribbons (black, 4.33”x1181LF), 1 case of premium paper labels (you choose the size)

Falcon 4 Printer Package – Small / Medium Industrial - $2,575

No attached PC required! The Falcon 4 printer has a revolutionary design – since the Falcon’s internal memory is capable of storing up to 4 standard label formats, it eliminates the need for a dedicated computer to print labels. A PC is only required when the printer is initialized to set up the standard label formats.

This printer is ideal in factory environments that are not PC friendly. Software is loaded into a PC where label formats are created and stored. Once created, the label formats are then downloaded via USB, Parallel, or Serial connection into the printer “memory”. Labels can be created with text, barcodes, graphics and “when printed” fields that allow for simple field changes at print time. A standard PC keyboard is used to access label formats and input information into the “when printed” fields. The Falcon 4 comes with a real time clock, a large backlit LCD and will print at 200 dpi, speeds up to 6 inches per second and holds full size ribbons and labels (diameters of rolls up to 8 inch).

Printer	Falcon 4
Duty	Light/Medium Duty Industrial
Printing resolution	200 dpi
Maximum Print Speed	6 inches/sec
Maximum Width	4.33 inches
Maximum Ribbon Length	1181 LF
Maximum Label Roll OD	8 inches
Warranty	1 year
Print Head Warranty	1 year / 1 million inches

Software: BarTender, LabelView or Label Matrix – your choice (text, barcode, graphics, database)

Accessories included: printer power cord; PC/printer connecting cable, 3 premium wax ribbons (black, 4.33”x 1476 LF), 1 case of premium paper labels (you choose the size)

TEC B-SX5 New Printer Package – Medium / Heavy Industrial - $4,155

The TEC B-SX5 can print labels up to 5” wide. The B-SX5 is a printer work horse and features stainless steel construction, print resolution of 305 dpi and print speeds of up to 8 inches per second. Optional features include internet, email, FTP, XML and BCI printing. Connection options include serial, bi-directional, parallel expansion I/O, PCMCIA, Ethernet and USB.

Printer	TEC B-SX5 (w/o cutter)
Duty	Medium/Heavy Duty Industrial
Printing resolution	300 dpi
Maximum Print Speed	8 inches/sec
Maximum Width	5.1 inches
Maximum Ribbon Length	1968 LF
Maximum Label Roll OD	8 inches
Warranty	1 year
Print Head Warranty	1 year / 2 million inches

Software: LabelView, Label Matrix or BarTender – your choice (text, barcode, graphics, database)

Accessories included: printer power cord; PC/printer connecting cable, 3 premium wax ribbons (black, 4.33”x 1968 LF), 1 case of premium paper labels (you choose the size)

TEC B572 "Refurbished" Barcode Printer

$1,395 + Delivery (While Supplies Last!!!)

The TEC B572 (shown with optional cutter) is our best value for an industrial printer, which can print labels up to 5” wide. The B572 is a printer work horse and features stainless steel construction, print resolution of 305 dpi and print speeds of up to 8 inches per second. Internal mechanisms have been “refurbished” and a new print head installed. The printer must be connected to a PC via serial connection.

Printer	TEC B572 (w/o cutter)
Duty	Medium/Heavy Duty Industrial
Printing resolution	305 dpi
Maximum Print Speed	8 inches/sec
Maximum Width	5.1 inches
Maximum Ribbon Length	1968 LF
Maximum Label Roll OD	8 inches
Warranty	90 Days

Avery Dennison TDI Printer Package – Single Tag Printer – $9,485
(without power stacker)

The TDI printer prints sheets (instead of rolls) of material up to .018” thick. It is a near-edge printer that prints at 300 dpi resolution and speeds up to 10 inches per second. The printhead pressure can be adjusted to maintain imprint quality in applications ranging from small brand-image garment tags to thicker, heavier blister-pack cards. Acceptable stock sizes range from single tags as small as 1.2" x 4.1", to tags strips and cards as large as 6" x 13.8" overall size. The software is full featured, single-user software able to print text, barcodes, graphics, paragraphs, pull from databases and much, much more.

Printer	Avery Dennison TDI	model shown Jumbo TDI with power stacker
Duty	Medium/Heavy Duty Industrial
Printing resolution	300 dpi
Maximum Print Speed	10 inches/sec
Maximum Width	6.0 inches (available in wider models)
Maximum Ribbon Length	1968 LF
Maximum Label Roll OD	n/a
Warranty	1 year
Print Head Warranty	1 year / 1 million inches
